| Video |
| Image Sensor |
1/2.8″ CMOS |
| Max. Resolution |
3840 x 2160 |
| Scanning Mode |
Progressive Scan |
| Lens Type |
Fixed-focal |
| Focal Length |
f=3.3mm |
| Aperture |
F2.0 |
| Iris Control |
Fixed Iris |
| Angular Field of View |
101.3º(H) 54.5º(V) 119.7º(D) |
| Pan/Tilt Range |
Pan: -170° ~ 170°, Tilt: -5° ~ 67.5°, Rotate: -109° ~ 109° |
| Min. Illumination |
COLOR : 0.2 lux F2.0
B/W : 0 lux (IR LED ON) |
| Dynamic Range |
120dB(True WDR) |
| Electronic Shutter Speed |
Auto / Manual (1/30 ~ 1/10000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
| Day and Night |
IR cut filter with auto switch |
| IR Distance (LEDs) |
30 m / 98.4 ft (4 ea) |
| Image Setting |
Exposure, White Balance, Self-Adjusting Video Mode(Sharpness, Contrast, Colors, Brightness Control) |
| Backlight Compensation |
On / Off |
| Mirroring / Pivot |
Horizontal / Vertical / Pivot |
| Image Stabilizer |
– |
| De-fog |
– |
| Privacy Masking |
8 Zones |
| Intelligent Video |
Video Motion Detection, Active Tampering Alarm, Trip Zone |
| Video Out |
– |
| Network |
| Video Compression |
H.265, H.264 (MP), M-JPEG |
| Intelligent Codec |
Supported |
| Bitrate Control |
H.264 – CBR / VBR, H.265 – CBR / VBR |
| Audio Compression |
ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law (except DC-D4811WRX-A) |
| Two-way Audio |
Yes (except DC-D4811WRX-A) |
| IP Camera Protocol |
DirectIP 2.0, ONVIF Profile S |
| Max. Frame Rate |
30ips : 3840 x 2160
15ips : 3840 x 2160(WDR) |
| Supports Resolution |
3840 x 2160, 1920 x 1080, 1280 x 720, 640 x 360 |
| Multi-video Streaming |
Quadruple Streaming |
| Network Protocols |
DirectIP 2.0 Protocol, IPv4, IPv6, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP, SNMPv2 |
| Security |
SSL Encryption, Multi-user Authority, IEEE 802.1x
IP Filtering, HTTPS |
| Remote Access Client |
DirectIP NVR Connection, IDIS Web, IDIS Mobile (Plus), IDIS Solution Suite, IDIS Cloud Manager |
| Ethernet |
RJ45 (10/100BASE-T) |
| Recording Session Buffer (NLTSrec) |
Yes (Up to 60MB) |
| Edge Storage |
micro SD/SDHC/SDXC, Smart Failover (Up to 512GB) |
| ALARM AND EVENT |
| Trigger Event |
Motion Detection, Alarm in, Audio Detection, Tampering, Trip Zone |
| Event Notification |
Remote S/W, Email (with Image) |
| Audio In/ Out |
1 / 1 (except DC-D4811WRX-A) |
| Alarm In / Out |
1 / 1 |
| Environmental |
| Vandal Proof Casing |
IK10 |
| Outdoor Ready |
IP67 |
| Operating Temperature |
-20°C ~ +55°C (-22°F ~ +131°F)
*Starting up at above 0°C (32°F) |
| Operating Humidity |
0% ~ 90% |
| Electrical |
| Power Source |
PoE (IEEE 802.3af Class 3) |
| Power Consumption |
PoE, IEEE 802.3af(Class 3), 9.0W |
| Approval |
FCC, CE, KC |
| Mechanical |
| Dimensions (Ø x H) |
Ø120 x 92.9mm |
| Weight |
0.48 kg |
