| Video |
| Beeld Sensor |
1/2.8″ CMOS |
| Max. Resolutie |
2592 x 1944 |
| Scanning Mode |
Progressive Scan |
| Lens type |
Gemotoriseerde Vari-focal |
| Brandpuntsafstand |
f=3.2-10.5mm |
| Opening |
F1.6 – 3.3 |
| Iris Control |
P-Iris |
| Kijkhoeken |
[4:3 mode]
Wide : 98,9º(H), 71,1º(V), 133,8º(D)
Tele : 28,2º(H), 21,2º(V), 35,3(D)[16:9 mode]
Wide : 98,9º(H), 52,2º(V), 117,9º(D)
Tele : 28,2º(H), 15,9º(V), 32,4º(D) |
| Pan/Tilt bereik |
Pan: -180° ~ 180°, Tilt: -5° ~ 70°, Rotate: -180° ~ 180° |
| Min. Verlichting |
KLEUR : 0.13 lux @ F1.6
Z/W : 0 lux (IR LED aan) |
| Dynamisch bereik |
120dB (True WDR) |
| Elektronische Shutter Snelheid |
Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
| Dag & Nacht |
IR cut filter met automatische schakelaar |
| IR Afstand (LED’s) |
50m (6ea) |
| Beeldinstelling |
Exposure, Witbalans, Zelfinstellende videomodus (Scherpte, Contrast, Kleuren, Helderheid) |
| Backlight Compensatie |
– |
| Mirroring / Pivot |
Horizontaal / Verticaal / Pivot |
| Beeldstabilisatie |
– |
| De-fog |
Ja |
| Privacy Masker |
8 Zones |
| Intelligent Video |
Video Motion Detection, Active Tampering Alarm, Object Detection, Intrusion, Loitering, Line Crossing, Face Detection |
| Video Uit |
– |
| Netwerk |
| Video Compressie |
H.265, H.264 (MP), M-JPEG |
| Intelligent Codec |
Ja |
| Bitrate Control |
H.265 – CBR / VBR, H.264 – CBR / VBR |
| Audio Compressie |
ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law |
| Two-way Audio |
Ja |
| IP Camera Protocol |
DirectIP 2.0, ONVIF Profile S/T |
| Max. Frame Rate |
4:3 mode : 30ips : 2592 x 1944(WDR)
16:9 mode : 30ips : 2592 x 1456(WDR) |
| Ondersteunde Resolutie |
4:3 : 2592×1944, 1920×1440, 1280x960x 640×480
16:9 : 2592×1456, 1920×1080, 1280×720, 640×360 |
| Multi-Video Streaming |
Quadruple streaming |
| Netwerk Protocollen |
DirectIP 2.0 Protocol, IPv4, IPv6, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP,
RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP, SNMPv2 |
| Beveiliging |
Digest authentication, Wachtwoord beveiliging, User access log, IP Filtering, IEEE802.1x(EAP-TLS), Chained Fingerprint, SSL Encryptie, HTTPS Encryptie |
| Remote Access Client |
DirectIP NVR verbinding, IDIS Web, IDIS Mobile (Plus), IDIS Solution Suite, IDIS Cloud Manager |
| Ethernet |
RJ45 (10/100BASE-T) |
| Opnamesessie Buffer (NLTSrec) |
Ja (tot 60MB) |
| Edge Opslag |
Micro SD/SDHC/SDXC, Smart Failover (tot 512GB) |
| Alarm & Event |
| Trigger Event |
Motion Detection, Alarm in, Audio detection, Tampering, Object Detection, Intrusion, Loitering, Line Crossing, Face Detection |
| Event Notificatie |
Remote S/W, Email (met plaatje) |
| Audio Alarm |
Ja |
| Audio In / Uit |
1 (ingebouwde MIC) + 1 / 1 |
| Alarm In / Uit |
1 / 1 |
| Omgeving |
| Vandaalbestendig |
IK10 |
| Outdoor Ready |
IP67, Heater |
| Bedrijfstemperatuur |
-40°C ~ +55°C
*Starting up at above -20°C |
| Bedrijfsvochtigheid |
0% ~ 90% |
| Elektrisch |
| Voeding |
12VDC, PoE(IEEE 802.3af Class 3) |
| Stroomverbruik |
12V= : 1,1A, 13,2W
PoE : IEEE 802.3af(Class 3), 11,5W |
| Goedkeuring |
FCC, CE, KC |
| Mechanisch |
| Afmetingen (Ø x H) |
Ø135mm x 98,5mm |
| Gewicht |
830g |
